FULTON ELECTRIC steam BOILERS

The Fulton Electric Steam Boiler range comes in three model series made up of the Mini Compack, Midi Compack and the Electropack

The range caters for small footprint boilers that are designed to fit into small spaces, through to more traditional higher capacity and higher pressure products.

Mini Compact

4 Models: 9kW - 17.5kW
Output: 14 kg/h - 29 kg/h (F&A 100°C)
Operating Pressure: 5.8 barg
Small and Compact

Midi Compact

3 Models: 24kW - 48kW
Output: 38 kg/h - 77 kg/h (F&A 100°C)
Operating Pressure: 10.34 bar

Electropack

The Electropack is Fulton’s versatile seven-model range designed for steam loads between 29 and 153kg/h. It is fully packaged in an attractive modern case and all services are connected at the rear for easy installation. The Electropack offers unrivalled flexibility and mobility in a compact unit that occupies minimal floorspace. It is easily moved to provide point-of-use steam wherever required and the heating elements are individually switched to allow the boiler to respond quickly and efficiently to variable steam demands.

The Electropack range is ideal for “clean environments” in applications such as pharmaceutical, medical, chemical and food and beverage processing. The EP18-EP72 models have an integrated feedwater tank and feedwater pump, all in one compact unit. The EP100 is supplied with a separate feedwater tank.

The Electropack will fit through a standard door opening, making it easy to install in office and laboratory environments.

7 Models: 18kW - 100kW
Output: 29 kg/h - 153 kg/h (F&A 100°C)
Operating Pressure: 10.34 bar
