FULTON J-SERIES VERTICAL BOILERS


The renowned Fulton J-Series vertical gas and oil-fired steam boilers includes five models covering outputs from 160 to 800 kg/h

Its tubeless design, invented by Fulton, eliminates the coils and tubes traditionally used in steam raising plant and enables the J-Series to typically raise its full steam output in just 20 minutes.  Its simple, compact design and robust construction from top quality materials makes them ideal for arduous applications in a wide range of industries and for numerous industrial, pharmaceutical, medical, food and beverage applications.

The design of the Fulton J-Series boiler provides increased thermal efficiency, with reduced flue gas and casing temperatures.  It is easy to service and maintain, with good access for cleaning and inspection of internal surfaces.


The key features of the product range include:

  • Made in Britain, Design Registered in Australia
  • Approved for Unattended Operation as per the requirements of AS2593
  • 5 Models: 100kW – 500kW
  • Output: 160 kg/h – 800 kg/h (F&A 100°C)
  • Operating Pressure: 10.34 barg
  • Modulating Burners Available, with fuel options of Oil, Natural Gas, LPG and Dual Fuel
  • Low NOx Natural Gas Burners as standard
  • Steam Output raised in Approx. 20 mins
  • Compact Design
  • Full range of Spare Parts always available
  • Five Year Guarantee on Pressure Vessel

Fulton 50J 500 kw Vertical Tubeless Steam Boiler


Boiler Water Conditioning skid to enable the most efficient installations

Fulton J-Series cut away showing internals and gas passes

Fulton J-Series boilers typical installation with designed redundancy and Lead/Lag control

Fulton J-Series boilers are efficiently installed using pre-fabricated Water Conditioning Skids

Fulton J-Series 'Drop and Go' plant rooms are available and can provide full steaming capacity within hours of arrival
